Product Description
Siemens GGA126.1E/12
Actuator for fire protection dampers, AC/DC 24 V, 2-position, 18 Nm, spring return 90/15 s, 2 auxiliary switches, shaft 12 x 12 mm
- Rotary type
- 2-position
- Spring return to failsafe position
- Fixed auxiliary switches for switching points 5 ° and 80 °
- Rigid connection between actuator and damper square shafts (12x12)
- Manual setting
- Position indicator
- Robust, lightweight all metal housing made from die-cast aluminium and 0.9 m connecting cable
- Degree of protection: Actuator IP54
Datasheet
The Siemens GGA126.1E/12 Actuator is a reliable and efficient solution for fire protection dampers, designed to ensure the safety of buildings in case of emergencies. This rotary type actuator operates on AC/DC 24V power and offers a sturdy 2-position function with a powerful 18 NM torque.
Equipped with a spring return feature, this actuator swiftly moves the damper to a failsafe position in just 90/15 seconds for optimal fire protection. Two fixed auxiliary switches enable precise switching points at 5° and 80°, while the rigid connection between the actuator and damper shafts (12x12mm) ensures a secure operation.
The robust all-metal housing of the Siemens GGA126.1E/12 Actuator is made from high-quality die-cast aluminum, providing durability and strength. Additionally, the actuator boasts a manual setting option, a position indicator, and comes with a 0.9m connecting cable for convenience. With a degree of protection rated at IP54, this actuator offers a high level of performance and safety for fire protection systems.
